SMART-BRICKS
What are SMART-BRICKS?
Smart Bricks These are prefabricated cross-laminated solid wood modules that can be assembled like an interlocking system to form exterior walls as well as load-bearing or non-load-bearing interior walls. The system has already been successfully installed in over 110,000 m² of wall surface and is suitable for single-family homes, multi-story residential buildings, and applications in agricultural, commercial, and municipal sectors.
The handy Smart Bricks consist of five layers of solid wood, crosswise bonded at specific points. This special layer structure creates dimensionally stable, non-deformable modules. The modules and additional components are manufactured using formaldehyde-free adhesives that meet the strictest requirements for structural performance, ecology, and health.
Positioned between a sill beam and the masonry-closing header, Smart Bricks combine the static wall structure and the installation layer in a single product.dwirtschaftlichen, gewerblichen und kommunalen Bereich.
What makes Smart-Bricks unique?
Simple Assembly
Thanks to prefabricated cross-laminated solid wood modules that can be assembled as a plug-in system to form exterior and interior walls
Sustainable Building Material
Smart-Bricks are made from high-quality wood sourced from European forests and are processed exclusively using selected, environmentally friendly adhesives
Lightweight Construction
Thanks to their design, Smart-Bricks can be used as an ideal lightweight component, weighing only about 33 kg/m², and are suitable for both renovations and new constructions
Quick Application
Thanks to the well-designed plug-in system and specially coordinated additional products, significant time savings can be achieved during installation compared to conventional building blocks
FAQs
What are the technical specifications of the Smart-Brick??
• Wall thickness: 160 mm
• Module weight: max. 6.5 kg
• Lengths: 160–640 mm / Heights: 240 & 320 mm
• Sound insulation: up to 53 dB
• Fire resistance: up to REI30; REI60, REI90
• Building height: up to 5 full storeys
What makes Smart-Brick stand out?
The core element of the Smart-Brick wall system is a wooden module that can be easily assembled layer by layer to create complete walls. The individual modules are connected to each other through a special interlocking system. Optimal corner joints and intermediate wall connections are ensured. Coordinated end pieces, lintels, and beams for various opening types simplify wall construction. Hollow chambers within the Smart-Bricks allow for the routing of tubular conduits
What is the structure of the Smart-Brick?
The handy Smart-Bricks consist of five layers of solid wood, crosswise bonded at specific points. This special layered structure creates dimensionally stable, non-deformable modules. The modules and additional components are manufactured using formaldehyde-free PUR adhesives that meet the strictest requirements for load-bearing performance, ecology, and health.
Where can Smart-Brick be applied??
The Smart-Brick wall system is suitable for all areas of building construction. Smart-Brick walls are used in single-family and multi-family housing, as well as in industrial, commercial, and municipal buildings, agriculture, extensions, renovations, temporary structures, and for infill in skeleton constructions.
What does the Smart-Brick wall structure look like?
Depending on the required U-value, external insulation can be applied. The façade can be finished with a ventilated timber cladding, façade panels, or any other ventilated façade system. For a simple façade design, compact façades with various insulation materials—similar to solid construction—are also an option; the insulation boards simultaneously serve as a plaster base. Inside, the walls can be left exposed or clad with freely selectable interior finishing mate
In what sizes is the Smart-Brick available?
Smart-Brick is available in 8 different sizes, with a constant depth of 160 mm.
We distinguish between two heights: the standard height is 320 mm, while the flat version is produced at 240 mm.
Smart-Bricks are manufactured in four different lengths: 160, 320, 480, and 640 mm, creating a horizontal grid of 160 mm..
